Input

Power Supply

1P+N+PE

3P+N+PE

Rated Voltage

230V   AC

400V   AC

Rated Current

64A

64A

Frequency

50/60Hz

50/60Hz

Output

Output Voltage

230V   AC

400V   AC

Maximum Current

2x32A

2x32A

Rated Power

2x7kW

2x22kW

User Interface

Charge Connector

                Type 2 socket

Enclosure

               Galvanized steel

Left/Right   Panel

                 Temper glass

LED Indicator

                Green/Yellow/Red

LCD Display

              2.7'' black & white screen

RFID Reader

             Mifare   ISO/IEC 14443 A

Start Mode

               Plug&Play/RFID   card/App

Emergency Stop

                    No

Communication

Wi-Fi

                   Yes

Ethernet

                    Yes

3G/4G

                    Yes

OCPP

              OCPP 1.6 Json (OCPP 2.0 optional)

Safety

Energy Meter

                 MID certified

RCD

             30mA   Type A + 6mA DC

Ingress Protection

                  IP54

Impact Protection

                  IK08

Electrical Protection

Over current protection,Residual current protection, Short circuit protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection,Over/Under temperature protection

Certification

                  CE

Certification   Standard

EN/IEC 61851-1:2019, EN/IEC 61851-21-2:2021

Warranty

               2   years

Environment

Installation

                Floor-stand

Work Temperature

                -30℃~+50℃

Work Humidity

                  5%~95%

Work Altitude

                   <2000m

Package

Product Dimension

          1450*350*160mm (H*W*D)

Package Dimension

          1550*450*190mm (L*W*H)

Net Weight

                  30kg

Gross Weight

                    35kg

External   Package

                  Wood case
