Input

Power Supply

                3P+N+PE

Rated Voltage

                400V   AC

Rated Current

                  50A

Frequency

                  50/60Hz

Output

Output Voltage

200~750V DC

150~500V   DC

Maximum Current

33A

50A

Rated Power

30kW

40kW

User Interface

Charge Connector

                  CCS2   cable

Cable Length

                     5m

Enclosure

                 Galvanized steel

LED Indicator

                    Green/Red

LCD Display

                   2.7'' black & white screen

RFID Reader

                 Mifare   ISO/IEC 14443 A

Start Mode

               Plug&Play/RFID card

Emergency Stop

                   Yes

Safety

Energy Meter

                    No

RCD

                    No

Ingress Protection

                    IP54

Impact Protection

                    IK08

Electrical Protection

   Over current protection,Short circuit protection, Ground protection,Surge protection, Over/Under voltage protection,Over/Under frequency protection, Over/Under temperature protection

Certification

                    CE

Certification   Standard

   EN/IEC 61851-1:2019, EN/IEC 61851-21-2:2021

Warranty

                   2   years

Environment

Installation

                  Wall-mount

Cooling Method

                   Fan cooling

Noise

                   ≤60dB

Work Temperature

                   -30℃~+50℃

Work Humidity

                    5%~95%

Work Altitude

                    <2000m

Package

Product Dimension

                556*406*189mm (H*W*D)

Package Dimension

                689*500*420mm (L*W*H)

Net Weight

                    29kg

Gross Weight

                    35kg

External Package

                    Carton
